Straight Bevel Right Angle Drives

190 items

Sort by:
Per page:
of 19

Grid List Table

Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, 1.5:1 Gear Ratio, 10.05 hp, Shaft Input, Shaft Output, 3/4 in Dia x 1-1/2 in L Input, 3/4 in Dia x 1-1/2 in L, 3/4 in Dia x 1-15/32 in L Output, 1166.7 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 516 in-lb, 5-3/16 in Center Distance, Four-Bolt Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, 1.5:1 Gear Ratio, 10.05 hp, Shaft Input, Shaft Output, 3/4 in Dia x 1-1/2 in L Input, 3/4 in Dia x 1-1/2 in L, 3/4 in Dia x 1-15/32 in L Output, 1166.7 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 516 in-lb, 5-3/16 in Center Distance, Four-Bolt Surface Mount, Cast Iron

IBT Part#: 00440006752

Mfr Part #: 0220-75462

$1534.27
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 1.5:1
- Input Size: 3/4 in Dia x 1-1/2 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, 1:1 Gear Ratio, 19.96 hp, Shaft Input, Shaft Output, 3/4 in Dia x 1-1/2 in L Input, 3/4 in Dia x 1-1/2 in L, 3/4 in Dia x 1-15/32 in L Output, 1750 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 719 in-lb, 5-3/16 in Center Distance, Four-Bolt Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, 1:1 Gear Ratio, 19.96 hp, Shaft Input, Shaft Output, 3/4 in Dia x 1-1/2 in L Input, 3/4 in Dia x 1-1/2 in L, 3/4 in Dia x 1-15/32 in L Output, 1750 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 719 in-lb, 5-3/16 in Center Distance, Four-Bolt Surface Mount, Cast Iron

IBT Part#: 00440006761

Mfr Part #: 0220-75460

$940.07
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 1:1
- Input Size: 3/4 in Dia x 1-1/2 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, 2:1 Gear Ratio, 5.95 hp, Shaft Input, Shaft Output, 3/4 in Dia x 1-1/2 in L Input, 3/4 in Dia x 1-1/2 in L, 3/4 in Dia x 1-15/32 in L Output, 875 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 429 in-lb, 5-3/16 in Center Distance, Four-Bolt Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, 2:1 Gear Ratio, 5.95 hp, Shaft Input, Shaft Output, 3/4 in Dia x 1-1/2 in L Input, 3/4 in Dia x 1-1/2 in L, 3/4 in Dia x 1-15/32 in L Output, 875 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 429 in-lb, 5-3/16 in Center Distance, Four-Bolt Surface Mount, Cast Iron

IBT Part#: 00440006770

Mfr Part #: 0220-75463

$1217.68
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 2:1
- Input Size: 3/4 in Dia x 1-1/2 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 11 Series, 1.47:1 Gear Ratio, 6.1 hp, Shaft Input, Shaft Output, 1 in Dia x 1-3/4 in L Input, 1 in Dia Output, 1190.5 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 330 in-lb, 6-1/8 in Center Distance, 1/4 x 1/8 in Input Keyway, Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 11 Series, 1.47:1 Gear Ratio, 6.1 hp, Shaft Input, Shaft Output, 1 in Dia x 1-3/4 in L Input, 1 in Dia Output, 1190.5 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 330 in-lb, 6-1/8 in Center Distance, 1/4 x 1/8 in Input Keyway, Surface Mount, Cast Iron

IBT Part#: 00440005987

Mfr Part #: 0220-00518

$1853.20
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 1.47:1
- Input Size: 1 in Dia x 1-3/4 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 11 Series, 1.8:1 Gear Ratio, 5.4 hp, Shaft Input, Shaft Output, 1 in Dia x 1-3/4 in L Input, 1 in Dia Output, 972.2 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 350 in-lb, 6-1/8 in Center Distance, 1/4 x 1/8 in Input Keyway, Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 11 Series, 1.8:1 Gear Ratio, 5.4 hp, Shaft Input, Shaft Output, 1 in Dia x 1-3/4 in L Input, 1 in Dia Output, 972.2 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 350 in-lb, 6-1/8 in Center Distance, 1/4 x 1/8 in Input Keyway, Surface Mount, Cast Iron

IBT Part#: 00440005996

Mfr Part #: 0220-00541

$1853.20
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 1.8:1
- Input Size: 1 in Dia x 1-3/4 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 11 Series, 1:1 Gear Ratio, 12 hp, Shaft Input, Shaft Output, 1 in Dia x 1-3/4 in L Input, 1 in Dia Output, 1150 rpm Output Maximum Speed, 1150 rpm Input Maximum Speed, 660 in-lb, 6-1/8 in Center Distance, 1/4 x 1/8 in Input Keyway, Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 11 Series, 1:1 Gear Ratio, 12 hp, Shaft Input, Shaft Output, 1 in Dia x 1-3/4 in L Input, 1 in Dia Output, 1150 rpm Output Maximum Speed, 1150 rpm Input Maximum Speed, 660 in-lb, 6-1/8 in Center Distance, 1/4 x 1/8 in Input Keyway, Surface Mount, Cast Iron

IBT Part#: 00440006008

Mfr Part #: 0220-00501

$1045.46
http://schema.org/InStock

/ Each
- Gear Ratio: 1:1
- Input Size: 1 in Dia x 1-3/4 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 1.5:1 Gear Ratio, 9.2 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 1 in Dia Output, 1166.7 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 500 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input Keyway, Four-Bolt Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 1.5:1 Gear Ratio, 9.2 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 1 in Dia Output, 1166.7 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 500 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input Keyway, Four-Bolt Surface Mount, Cast Iron

IBT Part#: 00440006275

Mfr Part #: 0220-00826

$1572.21
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 1.5:1
- Input Size: 1 in Dia x 2 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 1:1 Gear Ratio, 12 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 1 in Dia Output, 1150 rpm Output Maximum Speed, 1150 rpm Input Maximum Speed, 660 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input Keyway, Four-Bolt Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 1:1 Gear Ratio, 12 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 1 in Dia Output, 1150 rpm Output Maximum Speed, 1150 rpm Input Maximum Speed, 660 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input Keyway, Four-Bolt Surface Mount, Cast Iron

IBT Part#: 00440006305

Mfr Part #: 0220-00802

$992.78
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 1:1
- Input Size: 1 in Dia x 2 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 1:2 Gear Ratio, 7.2 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 5/8 in Dia Output, 2300 rpm Output Maximum Speed, 1150 rpm Input Maximum Speed, 195 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input, Four-Bolt Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 1:2 Gear Ratio, 7.2 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 5/8 in Dia Output, 2300 rpm Output Maximum Speed, 1150 rpm Input Maximum Speed, 195 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input, Four-Bolt Surface Mount, Cast Iron

IBT Part#: 00440006362

Mfr Part #: 0220-00834

$1399.29
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 1:2
- Input Size: 1 in Dia x 2 in L
- Input Type: Shaft
Order

QTY:

Add to List
Hub City

Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 2:1 Gear Ratio, 6-1/4 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 1 in Dia Output, 875 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 442 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input Keyway, Four-Bolt Surface Mount, Cast Iron Bevel Gear Reducer, Right Angle Straight Single Reduction Style A B, Series: 150, 2:1 Gear Ratio, 6-1/4 hp, Shaft Input, Shaft Output, 1 in Dia x 2 in L Input, 1 in Dia Output, 875 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 442 in-lb, 5-23/32 in Center Distance, 1/4 x 1/8 in Input Keyway, Four-Bolt Surface Mount, Cast Iron

IBT Part#: 00440006380

Mfr Part #: 0220-00818

$1244.97
http://schema.org/OutOfStock

/ Each
- Gear Ratio: 2:1
- Input Size: 1 in Dia x 2 in L
- Input Type: Shaft
Order

QTY:

Add to List
