Worms & Worm Gears

351 Products

View
content loaded
Helical Gear Worm, Spiral Tooth, 0.187 Inch Bore, 0.58 Inch Outside Diameter, 1 Threads, 24 Diametral Pitch, 1/2 Inch Pitch Diameter, 0.643 Inch Face Width, 4° 46 min Lead Angle, 0.893 Inch Overall Length, 14.5° Pressure Angle, Nylon
Boston Gear LUHBP
Helical Gear Worm, Spiral Tooth, 0.187 Inch Bore, 0.58 Inch Outside Diameter, 1 Threads, 24 Diametral Pitch, 1/2 Inch Pitch Diameter, 0.643 Inch Face Width, 4° 46 min Lead Angle, 0.893 Inch Overall Length, 14.5° Pressure Angle, Nylon
MFG #LUHBP
Ind. #30235689
IBT #00190114860
Factory Order
more info
$26.11Each
Sign In or Register for membership pricing
Helical Gear Worm, Spiral Tooth, 0.188 in Bore, 0.38 in OD, 1 Threads, 48 Diametral Pitch, 0.333 in Pitch Diameter, 0.563 in Face Width, 3° 35 min Lead Angle, 0.26 in Diameter Hub, 0.753 in Overall Length, 14.5° Pressure Angle, Steel
Boston Gear LF880TK3-1/4
Helical Gear Worm, Spiral Tooth, 0.188 in Bore, 0.38 in OD, 1 Threads, 48 Diametral Pitch, 0.333 in Pitch Diameter, 0.563 in Face Width, 3° 35 min Lead Angle, 0.26 in Diameter Hub, 0.753 in Overall Length, 14.5° Pressure Angle, Steel
MFG #LF880TK3-1/4
Ind. #LF880TABK
IBT #71688250
Factory Order
more info
$320.32Box
Sign In or Register for membership pricing
Helical Gear Worm, Spiral Tooth, 0.313 Inch Bore, 3/4 Inch Outside Diameter, 1 Threads, 16 Diametral Pitch, 5/8 Inch Pitch Diameter, 1 Inch Face Width, 5° 43 min Lead Angle, 0.43 Inch Diameter Hub, 1-1/4 Inch Overall Length, 14.5° Pressure Angle, Steel
Boston Gear HLVH-1
Helical Gear Worm, Spiral Tooth, 0.313 Inch Bore, 3/4 Inch Outside Diameter, 1 Threads, 16 Diametral Pitch, 5/8 Inch Pitch Diameter, 1 Inch Face Width, 5° 43 min Lead Angle, 0.43 Inch Diameter Hub, 1-1/4 Inch Overall Length, 14.5° Pressure Angle, Steel
MFG #HLVH-1
Ind. #30217388
IBT #00190004270
Factory Order
more info
$116.95Each
Sign In or Register for membership pricing
Helical Gear Worm, Spiral Tooth, 1-1/4 in Bore, 3-1/2 in OD, 1 Threads, 4 Diametral Pitch, 3 in Pitch Diameter, 5-3/4 in Face Width, 4° 46 min Lead Angle, Right Hand Direction of Rotation, 5-3/4 in Overall Length, 14.5° Pressure Angle, Steel
Boston Gear HLUH
Helical Gear Worm, Spiral Tooth, 1-1/4 in Bore, 3-1/2 in OD, 1 Threads, 4 Diametral Pitch, 3 in Pitch Diameter, 5-3/4 in Face Width, 4° 46 min Lead Angle, Right Hand Direction of Rotation, 5-3/4 in Overall Length, 14.5° Pressure Angle, Steel
MFG #HLUH
Ind. #30217387
IBT #00190004265
Factory Order
more info
$106.76Each
Sign In or Register for membership pricing
Helical Gear Worm, Spiral Tooth, 1/2 Inch Bore, 1.17 Inch Outside Diameter, 4 Threads, 12 Diametral Pitch, 1 Inch Pitch Diameter, 1-1/8 Inch Face Width, 18° 26 min Lead Angle, 3/4 Inch Diameter Hub, 1.505 Inch Overall Length, 14.5° Pressure Angle, Steel
Boston Gear DH1607
Helical Gear Worm, Spiral Tooth, 1/2 Inch Bore, 1.17 Inch Outside Diameter, 4 Threads, 12 Diametral Pitch, 1 Inch Pitch Diameter, 1-1/8 Inch Face Width, 18° 26 min Lead Angle, 3/4 Inch Diameter Hub, 1.505 Inch Overall Length, 14.5° Pressure Angle, Steel
MFG #DH1607
Ind. #30217303
IBT #00190001320
Factory Order
more info
$126.02Each
Sign In or Register for membership pricing
Helix Angle Worm, Bored-to-Size, 1 Inch Bore, 2.333 Inch Outside Diameter, 2 Threads, 6 Diametral Pitch, 2 Inch Pitch Diameter, 2-1/2 Inch Face Width, 9° 28 min Lead Angle, 2-1/2 Inch Overall Length, 14.5° Pressure Angle, Steel
Martin Sprocket & Gear W6D
Helix Angle Worm, Bored-to-Size, 1 Inch Bore, 2.333 Inch Outside Diameter, 2 Threads, 6 Diametral Pitch, 2 Inch Pitch Diameter, 2-1/2 Inch Face Width, 9° 28 min Lead Angle, 2-1/2 Inch Overall Length, 14.5° Pressure Angle, Steel
MFG #W6D
IBT #00568024155
Factory Order
more info
$167.11Each
Sign In or Register for membership pricing
00568024158
Martin Sprocket & Gear W6Q
Helix Angle Worm, Bored-to-Size, 1 Inch Bore, 2.333 Inch Outside Diameter, 4 Threads, 6 Diametral Pitch, 2 Inch Pitch Diameter, 2-1/2 Inch Face Width, 18° 26 min Lead Angle, 2-1/2 Inch Overall Length, 14.5° Pressure Angle, Steel
MFG #W6Q
IBT #00568024158
Factory Order
more info
$215.34Each
Sign In or Register for membership pricing
00568023834
Martin Sprocket & Gear W3
Helix Angle Worm, Bored-to-Size, 1-1/2 Inch Bore, 4.666 Inch Outside Diameter, Single Threads, 3 Diametral Pitch, 4 Inch Pitch Diameter, 4 Inch Face Width, 4° Lead Angle, Right Hand Direction of Rotation, 4 Inch Overall Length, 14.5° Pressure Angle, Steel
MFG #W3
IBT #00568023834
Factory Order
more info
$683.12Each
Sign In or Register for membership pricing
Helix Angle Worm, Bored-to-Size, 1-1/4 Inch Bore, 3-1/2 Inch Outside Diameter, 1 Threads, 4 Diametral Pitch, 3 Inch Pitch Diameter, 3-1/2 Inch Face Width, 4° 46 min Lead Angle, 3-1/2 Inch Overall Length, 14.5° Pressure Angle, Steel
Martin Sprocket & Gear WG4
Helix Angle Worm, Bored-to-Size, 1-1/4 Inch Bore, 3-1/2 Inch Outside Diameter, 1 Threads, 4 Diametral Pitch, 3 Inch Pitch Diameter, 3-1/2 Inch Face Width, 4° 46 min Lead Angle, 3-1/2 Inch Overall Length, 14.5° Pressure Angle, Steel
MFG #WG4
IBT #00568023165
Factory Order
more info
$844.04Each
Sign In or Register for membership pricing
00568023999
Martin Sprocket & Gear W4
Helix Angle Worm, Bored-to-Size, 1-1/4 Inch Bore, 3-1/2 Inch Outside Diameter, Single Threads, 4 Diametral Pitch, 3 Inch Pitch Diameter, 3-1/2 Inch Face Width, 4° Lead Angle, Right Hand Direction of Rotation, 14.5° Pressure Angle, Steel
MFG #W4
IBT #00568023999
Factory Order
more info
$388.65Each
Sign In or Register for membership pricing
