ShopIBT | AC Motor, 5 HP, 230/460 VAC, 11.4/5.7 A, 60 Hz Frequency, 3 ph, 3490 RPM Speed, 1 Speed, TEFC Enclosure, 184LP Frame, 1-1/8 in Dia Shaft, Reversible Rotation, 1.15 Service Factor, Medium Thrust Bearing, Vertical P-Base Mounting, 40 C°, Insulation Class: F, Cast Iron, 6:1 Constant Torque Speed, 22.18 in L Dimensions

VLECP3663T

AC Motor, 5 HP, 230/460 VAC, 11.4/5.7 A, 60 Hz Frequency, 3 ph, 3490 RPM Speed, 1 Speed, TEFC Enclosure, 184LP Frame, 1-1/8 in Dia Shaft, Reversible Rotation, 1.15 Service Factor, Medium Thrust Bearing, Vertical P-Base Mounting, 40 C°, Insulation Class: F, Cast Iron, 6:1 Constant Torque Speed, 22.18 in L Dimensions

Factory Order

MFG #VLECP3663T

IBT #00160313393

Industry Part #VLECP3663T

Get more details such as product availability, wishlist management and more when you register an IBT Industrial Solutions account.

: Amperage Rating: 11.4/5.7 Amps
Bearing Type: Medium Thrust
Constant Torque Speed Range: 6:1
Dimensions: 22.18 in L
Enclosure Type: TEFC
Frame: 184LP
Frequency Rating: 60 Hz
Horsepower: 5 HP
Insulation Class: F
Material: Cast Iron
Mounting Type: Vertical P-Base
Number of Speeds: 1
Phase: 3
Rotation: Reversible
Service Factor: 1.15
Shaft Size: 1-1/8 in Dia
Special Features: Severe Duty Motors, Vector (Inverter) Duty Motors
Speed: 3490 RPM
Temperature Rating: 40 °C
Type: Continuous-Duty
Voltage Rating: 230/460 VAC
Width: 16

: Baldor-Reliance solid shaft Vertical P-Base are the perfect power mates for centrifugal pumps, sump pumps , turbine pumps, in-line process pumps, fans, aerators , mixers, autoclaves, cooling towers and similar applications in industrial environments. These motors are available in a variety of enclosures and thrust values to suit your application. All frames have cast iron construction and premium features to protect motor components from chemicals, corrosion and abrasives, extending motor life and improving performance. Custom Vertical P-Base motors are available through 2250 HP. Baldor-Reliance AC Motor, Continuous-Duty, Severe Duty Motors, Vector (Inverter) Duty Motors Special Features, 5 HP, 230/460 VAC, 11.4/5.7 A, 60 Hz Frequency, 3 ph, 3490 RPM Speed, 1 Speed, TEFC Enclosure, 184LP Frame, 1-1/8 in Dia Shaft, Reversible Rotation, 1.15 Service Factor, Medium Thrust Bearing, Vertical P-Base Mounting, 40 °C, Insulation Class: F, Cast Iron, 6:1 Constant Torque Speed, 22.18 in L Dimensions
