ShopIBT | Keyless Locking Assembly, Series: C123, 180 mm Bore Diameter, 235 mm Outside Diameter, 13.137 Inch Hub Diameter, 27050 ft-lb Transmissible Torque, 91608 lbf Transmissible Thrust, 19794 PSI Shaft Contact Pressure, 15162 PSI Hub Contact, M14x40 Screw, 3.11 Inch Overall Length, 0 to 400 °F, Steel

C123M-180X235

Keyless Locking Assembly, Series: C123, 180 mm Bore Diameter, 235 mm Outside Diameter, 13.137 Inch Hub Diameter, 27050 ft-lb Transmissible Torque, 91608 lbf Transmissible Thrust, 19794 PSI Shaft Contact Pressure, 15162 PSI Hub Contact, M14x40 Screw, 3.11 Inch Overall Length, 0 to 400 °F, Steel

Factory Order

MFG #C123M-180X235

IBT #00280022490

Get more details such as product availability, wishlist management and more when you register an IBT Industrial Solutions account.

: Bore Diameter: 180 mm
Hub Diameter: 13.137 Inch
Material: Steel
Outside Diameter: 235 mm
Overall Length: 3.11 Inch
Screw Size: M14x40
Series: C123
Temperature Rating: 0 to 400 °F
Transmissible Thrust: 91608 lbf
Transmissible Torque: 27050 ft-lb

$0.00Each
