ShopIBT | Worm Gear Reducer, Double Reduction Right Angle, Series: 3200, 750:1 Gear Ratio, 0.46 hp Input, C-Face Quill Input, Shaft Output, 5/8 in Dia Input, 1.375 in Dia x 2.84 in L Output, 2.33 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 5560 in-

0230-30371

Worm Gear Reducer, Double Reduction Right Angle, Series: 3200, 750:1 Gear Ratio, 0.46 hp Input, C-Face Quill Input, Shaft Output, 5/8 in Dia Input, 1.375 in Dia x 2.84 in L Output, 2.33 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 5560 in-

Factory Order

MFG #0230-30371

IBT #00440103242

Industry Part #3204 750/1 WR 56C SINGLE OUTPUT

Get more details such as product availability, wishlist management and more when you register an IBT Industrial Solutions account.

: Centre Distance: 3-1/4 Inch
Dimensions: 10.88 in W
Efficiency: 44.9 %
Gear Ratio: 750:1
Horsepower: 0.46 hp Input
Input Maximum Speed: 1750 rpm
Input Size: 5/8 in Dia
Input Type: C-Face Quill
Keyway Size: 3/16 x 3/32 in Input, 5/16 x 5/32 in Output
Lubrication Type: Conventional Oil
Material: Cast Iron
Output Maximum Speed: 2.33 rpm
Output Size: 1.375 in Dia x 2.84 in L
Output Type: Shaft
Series: 3200
Torque Rating: 5560 in-lb Output
Type: Double Reduction Right Angle
Width: 12.25

: Hub City® PowerCubeX® Worm Gear Reducer, Double Reduction Right Angle, Series: 3200, 750:1 Gear Ratio, 0.46 HP Input, C-Face Quill Input, Shaft Output, 5/8 in Dia Input, 1.375 in Dia x 2.84 in L Output, 2.33 RPM Output Maximum Speed, 1750 RPM Input Maximum Speed, 5560 in-lb Output, 3-1/4 in Centre Distance, 3/16 x 3/32 in Input, 5/16 x 5/32 in Output Keyway, 44.9 % Efficiency, Conventional Oil Lubrication, Cast Iron, 10.88 in W
