60Q60

Roller Chain Sprocket, Type 4 Single Strand Welded Bushed, 0.75 to 2.688 Inch Bore, 14.761 Inch Outside Diameter, #60 Chain, 60 Teeth, 3/4 Inch Pitch, 14.3305 Inch Pitch Diameter, 4-1/4 Inch Diameter Hub, 1/2 Inch Keyway, 1-3/4 Inch Length Through Bore, MST® Q1 Bushing, Steel

Factory Order

MFG #60Q60

IBT #00568056897

Get more details such as product availability, wishlist management and more when you register an IBT Industrial Solutions account.

: Bore Diameter: 0.75 to 2.688 Inch
Bushing Type: MST® Q1
Chain Size: #60
Hub Diameter: 4-1/4 Inch
Keyway Size: 1/2 Inch
Length Through Bore: 1-3/4 Inch
Material: Steel
Number of Teeth: 60
Outside Diameter: 14.761 Inch
Pitch: 3/4 Inch
Pitch Diameter: 14.3305 Inch
Type: Type 4 Single Strand Welded Bushed
Width: 14.76

: Martin split taper sprocket is another style of bushed sprocket. The split taper bushing, when installed, offers a wide range of bore sizes. Martin Roller Chain Sprocket, Type 4 Single Strand Welded Bushed, 0.75 to 2.688 in Bore, 14.761 in OD, #60 Chain, 60 Teeth, 3/4 in Pitch, 14.3305 in Pitch Diameter, 4-1/4 in Diameter Hub, 1/2 in Keyway, 1-3/4 in Length Through Bore, MST® Q1 Bushing, Steel

$367.37Each

QTYQTY

Support Services

Learn more about our industrial rubber, engineering, gearing, specialty machining, and maintenance services here.

Martin Sprocket & Gear 60Q60Roller Chain Sprocket, Type 4 Single Strand Welded Bushed, 0.75 to 2.688 Inch Bore, 14.761 Inch Outside Diameter, #60 Chain, 60 Teeth, 3/4 Inch Pitch, 14.3305 Inch Pitch Diameter, 4-1/4 Inch Diameter Hub, 1/2 Inch Keyway, 1-3/4 Inch Length Through Bore, MST® Q1 Bushing, Steel
