MXT80 7 7/16
XT Bushing, MXT80, Series: MXT®, 7-7/16 in Bore Dia, 14.94 in Hub Dia, 12-7/8 in Bolt Circle Dia, 15-5/8 in Outside Dia, 1-3/8 in Flange Thickness, 4 Bolt Holes, 1-1/8 x 3-1/2 in Screw, For Use With: MXTH-80 XT Hub, 5-1/8 in Overall Length, 1-3/4 x 3
Factory Order
MFG #MXT80 7 7/16
IBT #00568079583
- Barrel Diameter: 11-1/8 InchBolt Circle Diameter: 12-7/8 InchBore Diameter: 7-7/16 InchFlange Thickness: 1-3/8 InchHub Diameter: 14.94 InchKeyway Size: 1-3/4 x 3/4 InchMaterial: Cast IronNumber of Bolt Holes: 4Overall Length: 5-1/8 InchScrew Size: 1-1/8 x 3-1/2 InchSuitable For Use With: MXTH-80 XT HubWidth: 15.63
- Martin's MXT® bushings are available from stock to fit all popular pulley sizes. Martin stocks MXT® bushings in a wide range of bore sizes per hub. The MXT® bushing offers a 2 in/ft taper, which reduces end disc pre-stressing, as well as increasing clamping force. All bushings size 50 and larger feature full depth keys. Martin MXT® Conveyor Bushing, 7-7/16 in Bore Dia, 11-1/8 in Barrel Dia, 14.94 in Hub Dia, 12-7/8 in Bolt Circle, 1-3/8 in Flange Thickness, 4 Bolt Holes, 1-1/8 x 3-1/2 in Screw, For Use With: MXTH-80 XT Hub, 5-1/8 in Overall Length, 1-3/4 x 3/4 in Keyway, Cast Iron
Martin Sprocket & Gear MXT80 7 7/16XT Bushing, MXT80, Series: MXT®, 7-7/16 in Bore Dia, 14.94 in Hub Dia, 12-7/8 in Bolt Circle Dia, 15-5/8 in Outside Dia, 1-3/8 in Flange Thickness, 4 Bolt Holes, 1-1/8 x 3-1/2 in Screw, For Use With: MXTH-80 XT Hub, 5-1/8 in Overall Length, 1-3/4 x 3
IBT #00568079583
MFG #MXT80 7 7/16
