5206NR
Double Row Angular Contact Ball Bearing, 30 mm Inside Diameter, 62 mm Outside Diameter, 0.9375 Inch Overall Width, 25° Contact Angle, Snap Ring, Steel Cage
Factory Order
MFG #5206NR
IBT #89900008465
- Bearing Material: High Carbon Chrome SteelBore Diameter: 30 mmCage Material: Pressed SteelClosure Type: OpenContact Angle: 25 degLoad Capacity: 29600 NMaximum Speed: 7100 rpm Grease/9500 rpm OilNumber Of Rows: 2Outside Diameter: 62 mmSeries: 52 SeriesTemperature Rating: -40 to 120 °CType: Round BoreWidth: 23.8 mm
- Double Row Angular Contact Ball Bearings have an inner and outer ring with a double raceway. The two rows are so related that the contact angle is similar to a pair of back-to-back single row bearings. The 5200 and 5300 series offer continuous races and can carry thrust loads in either direction. Since the 3200 and 3300 series have filling slots, it is necessary to mount them with the thrust load acting against the unnotched face of the rings. NTN Angular Contact Ball Bearing, Round Bore, Series: 52 Series, 30 mm Bore Dia, 62 mm Outside Dia, 2 Rows, 23.8 mm W, 25 °Contact, Open Closure, 29600 N, High Carbon Chrome Steel Bearing, Pressed Steel Cage, 7100 RPM Grease/9500 RPM Oil Maximum, -40 to 120 °C
NTN Bearing 5206NRDouble Row Angular Contact Ball Bearing, 30 mm Inside Diameter, 62 mm Outside Diameter, 0.9375 Inch Overall Width, 25° Contact Angle, Snap Ring, Steel Cage
IBT #89900008465
MFG #5206NR
