NNU4932KC1NAP4
Precision Cylindrical Roller Bearings, Large, Series: NNU, 160 mm Bore Dia, 220 mm Outside Dia, 2 Rows, 60 mm W, Open Closure, 740000 N, Hardened Alloy Steel Bearing, Machined Brass Cage, 2600 rpm Grease/3100 rpm Oil Maximum, -40 to 120 °C
Factory Order
MFG #NNU4932KC1NAP4
IBT #89900048958
- Bearing Material: Hardened Alloy SteelBore Diameter: 160 mmCage Material: Machined BrassClosure Type: OpenLoad Capacity: 740000 NMaximum Speed: 2600 rpm Grease/3100 rpm OilNumber Of Rows: 2Outside Diameter: 220 mmSeries: NNUTemperature Rating: -40 to 120 °CType: LargeWidth: 60 mm
- Cylindrical roller bearing, the rollers and raceways are in linear contact. Consequently this type of bearing can support a larger radial load than a point-contact ball bearing. Also, its structure is suitable for high-speed operation. A cylindrical roller bearing used for the main spindle of a machine tool can have either a double- or single row configuration, and certain variants have a tapered bore so the radial internal clearance can be adjusted. NTN Precision Cylindrical Roller Bearings, Large, Series: NNU, 160 mm Bore Dia, 220 mm Outside Dia, 2 Rows, 60 mm W, Open Closure, 740000 N, Hardened Alloy Steel Bearing, Machined Brass Cage, 2600 RPM Grease/3100 RPM Oil Maximum, -40 to 120 °C
NTN Bearing NNU4932KC1NAP4Precision Cylindrical Roller Bearings, Large, Series: NNU, 160 mm Bore Dia, 220 mm Outside Dia, 2 Rows, 60 mm W, Open Closure, 740000 N, Hardened Alloy Steel Bearing, Machined Brass Cage, 2600 rpm Grease/3100 rpm Oil Maximum, -40 to 120 °C
IBT #89900048958
MFG #NNU4932KC1NAP4
