ShopIBT | Right Angle Washdown Speed Reducer, Size 20, 20:1 Gear Ratio, 1.99 hp, Quill Input, Solid B Shaft Output, 1 in Output, 88 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 796 in-lb, 2 in Centre Distance, 1-3/4 in L x 1/4 in W x 1/4 in H Keyway

SS20Q20R56

Right Angle Washdown Speed Reducer, Size 20, 20:1 Gear Ratio, 1.99 hp, Quill Input, Solid B Shaft Output, 1 in Output, 88 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 796 in-lb, 2 in Centre Distance, 1-3/4 in L x 1/4 in W x 1/4 in H Keyway

Factory Order

MFG #SS20Q20R56

IBT #00325069415

Get more details such as product availability, wishlist management and more when you register an IBT Industrial Solutions account.

: Centre Distance: 2 Inch
Dimensions: 8.6 in L x 9.38 in W x 7.5 in H
Efficiency: 60 to 95 %
Gear Ratio: 20:1
Horsepower: 1.99 hp
Input Maximum Speed: 1750 rpm
Input Type: Quill
Keyway Size: 1-3/4 in L x 1/4 in W x 1/4 in H
Lubrication Type: Synthetic Oil
Material: Stainless Steel
Output Maximum Speed: 88 rpm
Output Size: 1 Inch
Output Type: Solid B Shaft
Rotation Type: Right Hand
Torque Rating: 796 in-lb
Type: Size 20

: Dodge® Ultra-Kleen® Tigear-2® is an all stainless steel worm gear reducer engineered for long life in sanitary washdown environments. Capable of withstanding high pressure washdowns and caustic chemicals, Ultra-Kleen® Tigear-2® is the ideal solution for food handling industrial applications. Dodge® Tigear-2® Ultra-Kleen® Right Angle Washdown Speed Reducer, Size 20, 20:1 Gear Ratio, 1.99 HP, Quill Input, Solid B Shaft Output, 1 in Output, 88 RPM Output Maximum Speed, 1750 RPM Input Maximum Speed, 796 in-lb, 2 in Centre Distance, 1-3/4 in L x 1/4 in W x 1/4 in H Keyway, 60 to 95 % Efficiency, Right Hand, Synthetic Oil Lubrication, Stainless Steel, 8.6 in L x 9.38 in W x 7.5 in H

$0.00Each

QTYQTY

Support Services

Learn more about our industrial rubber, engineering, gearing, specialty machining, and maintenance services here.

Dodge SS20Q20R56Right Angle Washdown Speed Reducer, Size 20, 20:1 Gear Ratio, 1.99 hp, Quill Input, Solid B Shaft Output, 1 in Output, 88 rpm Output Maximum Speed, 1750 rpm Input Maximum Speed, 796 in-lb, 2 in Centre Distance, 1-3/4 in L x 1/4 in W x 1/4 in H Keyway
